background image

20

8127B–AVR–08/09

ATtiny4/5/9/10

6.4

Starting

6.4.1

Starting from Reset

The internal reset is immediately asserted when a reset source goes active. The internal reset is
kept asserted until the reset source is released and the start-up sequence is completed. The
start-up sequence includes three steps, as follows.

1.

The first step after the reset source has been released consists of the device counting
the reset start-up time. The purpose of this reset start-up time is to ensure that supply
voltage has reached sufficient levels. The reset start-up time is counted using the inter-
nal 128 kHz oscillator. See

Table 6-1

for details of reset start-up time.

Note that the actual supply voltage is not monitored by the start-up logic. The device
will count until the reset start-up time has elapsed even if the device has reached suffi-
cient supply voltage levels earlier.

2.

The second step is to count the oscillator start-up time, which ensures that the cali-
brated internal oscillator has reached a stable state before it is used by the other parts
of the system. The calibrated internal oscillator needs to oscillate for a minimum num-
ber of cycles before it can be considered stable. See

Table 6-1

for details of the

oscillator start-up time.

3.

The last step before releasing the internal reset is to load the calibration and the config-
uration values from the Non-Volatile Memory to configure the device properly. The
configuration time is listed in

Table 6-1

.

Notes:

1. After powering up the device or after a reset the system clock is automatically set to calibrated

internal 8 MHz oscillator, divided by 8

6.4.2

Starting from Power-Down Mode

When waking up from Power-Down sleep mode, the supply voltage is assumed to be at a suffi-
cient level and only the oscillator start-up time is counted to ensure the stable operation of the
oscillator. The oscillator start-up time is counted on the selected main clock, and the start-up
time depends on the clock selected. See

Table 6-2

for details.

Notes:

1. The start-up time is measured in main clock oscillator cycles.

6.4.3

Starting from Idle / ADC Noise Reduction / Standby Mode

When waking up from Idle, ADC Noise Reduction or Standby Mode, the oscillator is already run-
ning and no oscillator start-up time is introduced.

The ADC is available in ATtiny5/10, only.

Table 6-1.

Start-up Times when Using the Internal Calibrated Oscillator

Reset

Oscillator

Configuration

Total start-up time

64 ms

6 cycles

21 cycles

64 ms + 6 oscillator cycles + 21 system clock cycles

(1)

Table 6-2.

Start-up Time from Power-Down Sleep Mode.

Oscillator start-up time

Total start-up time

6 cycles

6 oscillator cycles

(1)
