138
8127B–AVR–08/09
ATtiny4/5/9/10
Figure 17-31. Reset Pin as I/O, Input Threshold Voltage vs. V
CC
(V
IL
, I/O pin Read as ‘0’)
Figure 17-32. Reset Pin, Input Hysteresis vs. V
CC
RESET PIN AS I/O THRESHOLD VOLTAGE vs. VCC
V
IL
, RESET READ AS '0'
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Thre
s
hold (V)
RESET PIN INPUT HYSTERESIS vs. V
CC
85 °C
25 °C
-40 °C
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Inp
u
t Hy
s
tere
s
is
(V
)
