ATtiny4/5/9/10
BCLR
s
Flag Clear
SREG(s)
←
0
SREG(s)
1
SBI
A, b
Set Bit in I/O Register
I/O(A, b)
←
1
None
1
CBI
A, b
Clear Bit in I/O Register
I/O(A, b)
←
0
None
1
BST
Rr, b
Bit Store from Register to T
T
←
Rr(b)
T
1
BLD
Rd, b
Bit load from T to Register
Rd(b)
←
T
None
1
SEC
Set Carry
C
←
1
C
1
CLC
Clear Carry
C
←
0
C
1
SEN
Set Negative Flag
N
←
1
N
1
CLN
Clear Negative Flag
N
←
0
N
1
SEZ
Set Zero Flag
Z
←
1
Z
1
CLZ
Clear Zero Flag
Z
←
0
Z
1
SEI
Global Interrupt Enable
I
←
1
I
1
CLI
Global Interrupt Disable
I
←
0
I
1
SES
Set Signed Test Flag
S
←
1
S
1
CLS
Clear Signed Test Flag
S
←
0
S
1
SEV
Set Two’s Complement Overflow.
V
←
1
V
1
CLV
Clear Two’s Complement Overflow
V
←
0
V
1
SET
Set T in SREG
T
←
1
T
1
CLT
Clear T in SREG
T
←
0
T
1
SEH
Set Half Carry Flag in SREG
H
←
1
H
1
CLH
Clear Half Carry Flag in SREG
H
←
0
H
1
DATA TRANSFER INSTRUCTIONS
MOV
Rd, Rr
Copy Register
Rd
←
Rr
None
1
LDI
Rd, K
Load Immediate
Rd
←
K
None
1
LD
Rd, X
Load Indirect
Rd
←
(X)
None
1/2
LD
Rd, X+
Load Indirect and Post-Increment
Rd
←
(X), X
←
X + 1
None
2
LD
Rd, - X
Load Indirect and Pre-Decrement
X
←
X - 1, Rd
←
(X)
None
2/3
LD
Rd, Y
Load Indirect
Rd
←
(Y)
None
1/2
LD
Rd, Y+
Load Indirect and Post-Increment
Rd
←
(Y), Y
←
Y + 1
None
2
LD
Rd, - Y
Load Indirect and Pre-Decrement
Y
←
Y - 1, Rd
←
(Y)
None
2/3
LD
Rd, Z
Load Indirect
Rd
←
(Z)
None
1/2
LD
Rd, Z+
Load Indirect and Post-Increment
Rd
←
(Z), Z
←
Z+1
None
2
LD
Rd, -Z
Load Indirect and Pre-Decrement
Z
←
Z - 1, Rd
←
(Z)
None
2/3
LDS
Rd, k
Store Direct from SRAM
Rd
← (
k)
None
1
ST
X, Rr
Store Indirect
(X)
←
Rr
None
1
ST
X+, Rr
Store Indirect and Post-Increment
(X)
←
Rr, X
←
X + 1
None
1
ST
- X, Rr
Store Indirect and Pre-Decrement
X
←
X - 1, (X)
←
Rr
None
2
ST
Y, Rr
Store Indirect
(Y)
←
Rr
None
1
ST
Y+, Rr
Store Indirect and Post-Increment
(Y)
←
Rr, Y
←
Y + 1
None
1
ST
- Y, Rr
Store Indirect and Pre-Decrement
Y
←
Y - 1, (Y)
←
Rr
None
2
ST
Z, Rr
Store Indirect
(Z)
←
Rr
None
1
ST
Z+, Rr
Store Indirect and Post-Increment.
(Z)
←
Rr, Z
←
Z + 1
None
1
ST
-Z, Rr
Store Indirect and Pre-Decrement
Z
←
Z - 1, (Z)
←
Rr
None
2
STS
k, Rr
Store Direct to SRAM
(k)
←
Rr
None
1
IN
Rd, A
In from I/O Location
Rd
←
I/O (A)
None
1
OUT
A, Rr
Out to I/O Location
I/O (A)
←
Rr
None
1
PUSH
Rr
Push Register on Stack
STACK
←
Rr
None
2
POP
Rd
Pop Register from Stack
Rd
←
STACK
None
2
MCU CONTROL INSTRUCTIONS
BREAK
Break
(see specific descr. for Break)
None
1
NOP
No Operation
None
1
SLEEP
Sleep
(see specific descr. for Sleep)
None
1
WDR
Watchdog Reset
(see specific descr. for WDR)
None
1
Mnemonics
Operands
Description
Operation
Flags
#Clocks
