132
8127B–AVR–08/09
ATtiny4/5/9/10
17.2.5 Pin Driver Strength
Figure 17-19. I/O Pin Output Voltage vs. Sink Current (V
CC
= 1.8V)
Figure 17-20. I/O Pin Output Voltage vs. Sink Current (V
CC
= 3V)
I/O PIN OUTPUT VOLTAGE vs. SINK CURRENT
V CC = 1.8V
85 °C
25 °C
-40 °C
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
I
OL
(mA)
V
OL
(V)
I/O PIN OUTPUT VOLTAGE vs. SINK CURRENT
V CC = 3V
85 °C
25 °C
-40 °C
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0 1 2 3 4 5 6 7 8 9 10
I
OL
(mA)
V
OL
(V)
