Token Ring Menu
1-78 ❖ DocuPrint NC60 System Administrator Guide
Subnet Mask
Set the four byte Subnet Mask
address.
The available values are:
xxx.xxx.xxx.xxx
(where xxx = 000 to 255)
For this item (after Step 3), Item Up
moves the cursor to the right through
the displayed Subnet Mask address
and Item Down moves the cursor to
the left. This allows you to change
characters within the string rather
than having to reenter the entire
string.
With the cursor displayed under a
character, Value Up increments the
value of that character and Value
Down decrements the value.
This item appears only if
IP Address Res is set to Static.
1. Press Menu Up or Menu
Down until you see:
Menus
Token Ring Menu
2. Press Item Up or Item Down
until you see:
Token Ring Menu
Subnet Mask
3. Press Value Up or Value Down.
You will see:
Subnet Mask =
xxx.xxx.xxx.xxx
4. Press Value Up or Value Down
to change the value of the
character above the cursor. The
value is incremented or
decremented by 1 each time
the key is pressed. Holding
down Value Up or Value
Down causes continuous
scrolling through the values.
Subnet Mask =
xxx.xxx.xxx.xxx
5. To change other characters in
the Subnet Mask address, press
Item Up or Item Down to
scroll right or left respectively
through the character string,
then press Value Up or Value
Down to change the value of
the character above the cursor
(as in Step 4).
Subnet Mask =
xxx.xxx.xxx.xxx
6. When you have completed
setting the Subnet Mask
address, press Enter. You will
see:
Token Ring Menu
Subnet Mask
7. Press Online. You will see: Ready
8. Restart printer or power off/on.
Table 1.16 Token Ring Menu functions (continued)
Menu Item and Function Keystrokes Display
Table 1.16 Page 8 of 12
