Ethernet Menu
Chapter 1: Configuring the Printer ❖ 1-67
Default Gateway
Set the four byte Default Gateway
address.
The available values are:
xxx.xxx.xxx.xxx
(where xxx = 000 to 255)
For this item (after Step 3), Item Up
moves the cursor to the right through
the displayed Default Gateway
address and Item Down moves the
cursor to the left. This allows you to
change characters within the string
rather than having to reenter the
entire string.
With the cursor displayed under a
character, Value Up increments the
value of that character and Value
Down decrements the value.
This item appears only if
IP Address Res is set to Static.
1. Press Menu Up or Menu
Down until you see:
Menus
Ethernet Menu
2. Press Item Up or Item Down
until you see:
Ethernet Menu
Default Gateway
3. Press Value Up or Value Down.
You will see:
Default Gateway=
xxx.xxx.xxx.xxx
4. Press Value Up or Value Down
to change the value of the
character above the cursor. The
value is incremented or
decremented by 1 each time
the key is pressed. Holding
down Value Up or Value
Down causes continuous
scrolling through the values.
Default Gateway=
xxx.xxx.xxx.xxx
5. To change other characters in
the Default Gateway address,
press Item Up or Item Down
to scroll right or left
respectively through the
character string, then press
Value Up or Value Down to
change the value of the
character above the cursor (as
in Step 4).
Default Gateway=
xxx.xxx.xxx.xxx
6. When you have completed
setting the Default Gateway
address, press Enter. You will
see:
Ethernet Menu
Default Gateway
7. Press Online. You will see: Ready
8. Restart printer or power off/on.
Table 1.15 Ethernet Menu functions (continued)
Menu Item and Function Keystrokes Display
Table 1.15 Page 9 of 10
