LOGIC
5-43
Chapter 5
Logic circuit (Logic 11C)
Y0
X0, X1
X2, X3
T4, X4, T5, X5
T6, X6, T7, X7
T12, X12, T13, X13
T10, X10, T11, X11
T14, X14
T15, X15
X16
X17
Y1
Y2
Y3
Safety output 1
Safety output 2
Safety input 1
Safety input 6
Safety input 5
Safety input 4
Safety input 3
Safety input 2
Start input 1
Start input 2
External device
monitor 2
External device
monitor 1
&
=2k+1
Control
Control
Start
Hold
EDM
OSSD
OS1
S1
Dual Channel Safety
Dual Channel Safety
Hold
EDM
OSSD
with
Off delay
External Device
Monitor
EDM
External Device
Monitor
EDM
Single Channel
Monitor
Single Channel
Monitor
Dual Channel
Direct Opening
Dual Channel
Direct Opening
Dual Channel
Direct Opening
Dual Channel
Direct Opening
Hold
Trigger
Self-hold
function
Self-hold
function circuit 1
OS1
Y12
Y13
X 1
X 0
Y4
X 3
X 2
Y5
X 5
X 4
Y6
X 7
X 6
Y7
X 11
X 10
Y10
X 13
X 12
Y11
● Monitor output for safety input ● Monitor output for safety output ● Solenoid output
S1
Y0,Y1
Y17
S1
Y2,Y3
Y20
Y0,Y1
Y2,Y3
Safety input 1
monitor
Safety input 2
monitor
Safety input 3
monitor
Safety input 4
monitor
Safety input 5
monitor
Safety input 6
monitor
Safety output 1
monitor
Safety output 2
monitor
(Note1)
&
&
&
&
&
&
&
&
&
Note1:
Safety output 2 monitor turns OFF
immediately independent of OFF-delay
time. Note2:
In Run state, when the safety outputs are OFF and
one or more safety inputs are OFF, the solenoid
outputs turn ON.
When all safety inputs are ON, the solenoid outputs
turn OFF, even when the start input is OFF.
(Note2)
Solenoid output 1
Solenoid output 2
