IDEC FS1A Controller - Manual (Page 114)

LOGIC
5-66
Example: Control start input (X17) is used.
Safety input 1:
X0, X1
Start input 2: X17
(Control)
Monitor output for
safety input 1: Y4
Monitor output for
Safety output 1: Y12
Muting lamp output 1:
Y17
OFF delay time
Muting input 1: X2
State monitor output 3:
Y16
note 1)
Max. 6s
Initialization
0.1s to 5s
Muting input 1: X3
note 1)
note 3)
Safety output 1:
Y0, Y1
Max. 0.1s
Safety output 2:
Y2, Y3
Monitor output for
Safety output 2: Y13
note 2)
Muting
start
Muting
end
Muting
start
Muting
end
Power
ON
Safety
output
ON
Safety
output
ON
note 3)
0.1s to 5s
Max. 0.1s
(Safety input 2, 3 and 4 are all ON and muting input 2 is OFF in this chart.)
