IDEC FS1A Controller - Manual (Page 299)

LOGIC
5-251
Chapter 5
●Start inputs: X16 and X17
Start inputs are used to control the start of safety outputs.
Intended inputs
(Terminal names) Target safety inputs
(Terminal names) Function
Function name Monitor input
Symbol
Single Channel
Monitor
Description of
operation Safety outputs are started, when
all target safety inputs are in the
safe state and this function is in
the ON state. This function is
turned ON by 0.1s or more ON
operation.
Start input 1
(X16) Safety input 1
(X0-T0: TEACH)
Safety input 2
(X2-T2, X3-T3)
Detail information Logic functions (5-325)
Intended inputs
(Terminal names) Target safety
inputs
(Terminal
names) Function
Function name Monitor input + Control start
Symbol
Single Channel
Monitor
+
Control
Start
Control
Description of
operation Safety outputs are started, when this function
becomes ON after all intended safety inputs are
in the safe state. This function is turned ON by
0.1s to 5s ON operation.
Start input 2
(X17) Safety input 1
(X1-T0: AUTO)
Safety input 3
(X4-T4, X5-T5)
Safety input 4
(X6-T6, X7-T7)
Safety input 5
(X10, X11)
Detail
information Logic functions (5-325, 330)
