LOGIC
5-295
Chapter 5
Example: Control start input (X17) is used.
Max. 0.1s
Safety input 1: X0
Safety output 1-1:
Y0
Monitor output for
safety input 1: Y4
Monitor output for Safety
output 1-1: Y12
Safety input 2:
X2, X3
Safety output 2-1:
Y2
Monitor output for
Safety output 2-1: Y17
Monitor output for Safety
output 2-2: Y20
Start input 2: X17
(Control)
Monitor output for
safety input 4: Y7
Monitor output for Safety
output 1-2: Y13
State monitor output 3:
Y16
Max 6s.
Initialization
Safety input 1: X1
note 1)
Monitor output for
safety input 2: Y5
Safety input 4:
X6, X7
Safety output 1-2:
Y1
Safety output 2-2:
Y3
note 1)
OFF delay time
OFF delay time
OFF delay time
OFF delay time
ON
Power
ON
ON
ON
ON
Safety
output
1, 2
Safety
output
1, 2
Safety
output 1
Safety
output 2
0.1s to 5s
(Both safety input 3 and 5 are ON in this chart.)
