LOGIC
5-128
Wiring example (Logic 12d)
In the case where 1 emergency stop switch, 3 interlock switches, and 1 safety light curtain are connected.
S1 :Emergency stop switch
S2, 3, 4 :Interlock switch
S5 :Safety
light curtain
S6 :Start switch
S7, 8 :Control input switch
K1 to 4 :Contactor
M1, 2
:Motor
0V DC
X0
X1
X2
X3
T0
T1
T2
T3
X5
X6
X7
T5
T6
T7
X10
T10
X11
T11
X12
T12
X13
T13
X14
T14
X15
T15
K1 K2
K3 K4
X16
X17
FE
V+ V-
24V DC
SafetyOne
K1
Y4
Y5
Y6
Y7
Y10
Y11
Y12
Y13
Y14
Y15
Y17
Y20
Y0
Y16
K2 Y1
K3 Y2
K4 Y3
S2
T4
T4
S1
S3
S4
S6
S7
S8
S5
24V
0V
OSSD1
OSSD2
To
PLC
Fuse
K2
K1
M1
K4
K3
M2
