IDEC FS1A Controller - Manual (Page 241)

LOGIC
5-193
Chapter 5
Wiring example (Logic 13d)
In the case where 2 selector switches, 2 enabling switches, 1 safety light curtains, and 1 emergency stop switch
are connected.
S1, 2
:Selector switch
S3, 4 :Enabling switch
S5 :Safety light curtain
S6 :Emergency stop switch
S7, 8 :Start switch
K1 to 4 :Contactor
M1, 2
:Motor
Fuse
V+
X0
X1
X2
X3
T0
T1
T2
T3
X5
T5
X4
T4
X14
T14
X15
T15
X16
X17
K1
V-
Y4
Y5
Y6
Y7
Y10
Y11
Y12
Y13
Y14
Y15
Y20
Y0
Y16
K2 Y1
Y2
Y3
FE
24V DC 0V DC
SafetyOne
K5
K6
S6
S7
X10
T10
X11
T11
X12
T12
X13
T13
To
PLC
S2
S1
X6
X7
T6
T7
S4
S3
S8
S5
24V
0V
OSSD1
OSSD2
Y17
K1 K2
K3 K4
K2
K1
M1
K4
K3
M2
