LOGIC
5-211
Chapter 5
Logic circuit (Logic 14A)
Safety input 1
T0, X0, X1
Teach mode
Auto mode
Y0
Y1
Y2
Y3
T2, X2, T3, X3
Safety input 2
T4, X4, T5, X5
T6, X6, T7, X7
T10, X10, T11, X11
T14, X14
T15, X15
X16
X17
Safety input 5
Safety input 4
Safety input 3
Start input 1
Start input 2
External device
monitor 4
External device
monitor 3
Contorl
Start
Control
T12, X12
T13, X13
External device
monitor 2
External device
monitor 1
>=1
Safety output
1-1
Safety output
2-1
Safety output
1-2
Safety output
2-2
OS1
OS2
&
Mode
Select
Ⅱ
&
&
&
Single Channel
Monitor
Single Channel
Monitor
Dual Channel
Direct Opening
Dual Channel
Direct Opening
Dual Channel
Direct Opening
Dual Channel
D
ependent
External Device
Monitor
EDM
External Device
Monitor
EDM
External Device
Monitor
EDM
External Device
Monitor
EDM
Hold
Trigger
Self-hold
function
Self-hold
function circuit 3
Hold
Trigger
Self-hold
function
Self-hold function circuit 2
Hold
Trigger
Self-hold
function
Self-hold function circuit 1
Hold
EDM
OSSD
Hold
EDM
OSSD
Hold
EDM
OSSD
with
Off delay
Hold
EDM
OSSD
with
Off delay
●
Monitor output for safety input
●
Monitor output for safety output
(Note1)
X0
Y4
Safety inptut 1
monitor
X3
X2
Y5
X5
X4
Y6
X7
X6
Y7
X11
X10
Y10
Safety input 2
monitor
Safety input 3
monitor
Safety input 4
monitor
Safety ilnput 5
monitor
&
&
&
&
OS1
Y12
Y13
Y0
Y1
Safety output 1-1
monitor
Safety output 1-2
monitor
(Note2)
&
OS2
Y17
Y20
Y2
Y3
&
Safety output 2-1
monitor
Safety output 2-2
monitor
(Note2)
Note2:
Safety output 1-2 and safety output 2-2 turn
OFF immediately independent of OFF-delay
time.
Note1:
When safety input 1 is set to Auto
mode, safety input 1 monitor turns
OFF.
