13 Directory of the Parameters in Installer Mode and Expert Mode SMA Solar Technology AG
90 SI30M-44M-60H-80H-BE-en-30 Operating Manual
13 Directory of the Parameters in Installer Mode and Expert Mode
13.1 Display Values
13.1.1 Inverter (110#)
111# Total
112# Device
No. Name Description
111.01 TotInvPwrAt Total active power of Sunny Island inverters in a cluster in kW. ✓ ✓
111.02 TotInvCur Total current of Sunny Island inverters in a cluster in A ✓ ✓
111.03 TotInvPwrRt Total reactive power of Sunny Island inverters in a cluster in kVAr (expert mode) ✓ ✓
111.05 TotLodPwr Total current active power of the loads in a cluster in kW ✓ ✓
111.06 TotMccLodPwr Total current active power of the loads in a multicluster system in kW ✖ ✓
No. Name Description Value
(plain text no.)
Explanation
112.01 InvOpStt Operating state of the Sunny Island
inverter
Init (1) Initialization ✓ ✓
Startup (2) Switch from standby
to operation
Standby (3) Standby
Run (4) Operation
I-Loop (5) Current-controlled
generator operation
Error (6) Error status
112.02 InvPwrAt Active power of the Sunny Island
inverter in kW
‒ ‒ ✓ ✓
112.03 InvVtg Voltage of the Sunny Island inverter
in V
‒ ‒ ✓ ✓
112.04 InvCur Current of the Sunny Island inverter
in A
‒ ‒ ✓ ✓
112.05 InvFrq Voltage frequency of the Sunny Island
inverter in Hz
‒ ‒ ✓ ✓
112.06 InvPwrRt Reactive power of the Sunny Island
inverter in kVAr (expert mode)
‒ ‒ ✓ ✓
112.07 Rly1Stt Status of multifunction relay 1 Off Multifunction relay is
deactivated.
✓ ✓
On Multifunction relay is
activated.
