HEIDENHAIN TNC 320 451
Table of Miscellaneous Functions
M Effect Effective at block Start End Page
M00 Stop program/Spindle STOP/Coolant OFF
„
Page 162
M01 Optional program STOP „ Page 394
M02 Stop program/Spindle STOP/Coolant OFF/Clear status display
(depending on machine parameter)/Go to block 1 „ Page 162
M03
M04
M05 Spindle ON clockwise
Spindle ON counterclockwise
Spindle STOP „
„
„
Page 162
M06 Tool change/Stop program run (machine-dependent function)/Spindle STOP „ Page 162
M08
M09 Coolant ON
Coolant OFF
„
„
Page 162
M13
M14 Spindle ON clockwise/Coolant ON
Spindle ON counterclockwise/Coolant ON „
„
Page 162
M30 Same function as M02 „ Page 162
M89 Vacant miscellaneous function or
Cycle call, modally effective (machine-dependent function)
„
„
Page 179
M91 Within the positioning block: Coordinates are referenced to machine datum „ Page 163
M92 Within the positioning block: Coordinates are referenced to position defined by machine
tool builder, such as tool change position „ Page 163
M94 Reduce display of rotary axis to value under 360°
„
Page 174
M97 Machine small contour steps „ Page 165
M98 Machine open contours completely „ Page 167
M99 Blockwise cycle call
„
Page 179
M101
M102 Automatic tool change with replacement tool if maximum tool life has expired
Cancel M101 „
„
Page 108
M107
M108 Suppress error message for replacement tools
Cancel M107 „
„
Page 107
M109
M110
M111
Constant contouring speed at tool cutting edge
(increase and decrease feed rate)
Constant contouring speed at tool cutting edge
(feed rate decrease only)
Cancel M109/M110
„
„
„
Page 167
M116
M117 Feed rate for rotary tables in mm/minn
Cancel M116
„
„
Page 172
M118 Superimpose handwheel positioning during program run „ Page 169
