100 5 Programming: Tools
5.2 T
o
ol D
a
ta
Entering tool data in the table
You can define and store up to 9999 tools and their tool data in a tool
table. Also see the Editing Functions later in this Chapter. In order to
be able to assign various compensation data to a tool (indexing tool
number), insert a line and extend the tool number by a point and a
number from 1 to 9 (e.g. T 5.2).
You must use tool tables if
„
you wish to use indexed tools such as stepped drills with more than
one length compensation value (
"VF s¢)
„ your machine tool has an automatic tool changer
„
you want to rough-mill the contour with Cycle 22 (see “ROUGH-
OUT (Cycle 22)” on page 262)
Tool table: Standard tool data
Abbr. Input Dialog
T Number by which the tool is called in the program
(e.g. 5, indexed: 5.2) –
NAME Name by which the tool is called in the program Tool name?
L Value for tool length compensation L Tool length?
R Compensation value for the tool radius R Tool radius R?
R2 Tool radius R2 for toroid cutters (only for 3-D radius compensation
or graphical representation of a machining operation with
spherical or toroid cutters) Tool radius R2?
DL Delta value for tool length L Tool length oversize?
DR Delta value for tool radius R Tool radius oversize?
DR2 Delta value for tool radius R2 Tool radius oversize R2?
TL Set tool lock (TL: Tool Locked) Tool locked?
Yes = ENT / No = NO ENT
RT Number of a replacement tool, if available (RT: for Replacement
Tool; see also TIME2 Replacement tool?
TIME1 Maximum tool life in minutes. This function can vary depending
on the individual machine tool. Your machine manual provides
more information on TIME1. Maximum tool age?
TIME2 Maximum tool life in minutes during TOOL CALL: If the current tool
age exceeds this value, the TNC changes the tool during the next
TOOL CALL
(see also CUR.TIME).
Maximum tool age for TOOL CALL?
CUR.TIME Current age of the tool in minutes: The TNC automatically counts
the current tool life (CUR.TIME). A starting value can be entered for
used tools. Current tool life?
