HEIDENHAIN TNC 320 19
8.5 SL Cycles ..... 254
Fundamentals ..... 254
Overview of SL Cycles ..... 256
CONTOUR (Cycle 14) ..... 256
Overlapping contours ..... 257
CONTOUR DATA (Cycle 20) ..... 260
PILOT DRILLING (Cycle 21) ..... 261
ROUGH-OUT (Cycle 22) ..... 262
FLOOR FINISHING (Cycle 23) ..... 263
SIDE FINISHING (Cycle 24) ..... 264
8.6 Cycles for Multipass Milling ..... 268
Overview ..... 268
MULTIPASS MILLING (Cycle 230) ..... 268
RULED SURFACE (Cycle 231) ..... 270
FACE MILLING (Cycle 232) ..... 273
8.7 Coordinate Transformation Cycles ..... 281
Overview ..... 281
Effect of coordinate transformations ..... 281
DATUM SHIFT (Cycle 7) ..... 282
DATUM SHIFT with datum tables (Cycle 7) ..... 283
MIRROR IMAGE (Cycle 8) ..... 286
ROTATION (Cycle 10) ..... 288
SCALING FACTOR (Cycle 11) ..... 289
AXIS-SPECIFIC SCALING (Cycle 26) ..... 290
8.8 Special Cycles ..... 293
DWELL TIME (Cycle 9) ..... 293
PROGRAM CALL (Cycle 12) ..... 294
ORIENTED SPINDLE STOP (Cycle 13) ..... 295
