416 13 Touch Probe Cycles in the Manual and Electronic Handwheel Modes
13.1 Intr
oduction
13.1 Introduction
Overview
The following functions are available in the Manual mode:
Selecting probe cycles
8 Select the Manual Operation or Electronic Handwheel mode of
operation.
8 To choose the touch probe functions, press the
TOUCH PROBE soft key. The TNC displays additional
soft keys—see table above.
8 To select the probe cycle, press the appropriate soft
key, for example PROBING ROT, and the TNC
displays the associated menu.
Function Soft key Page
Calibrate the effective length Page 417
Calibrate the effective radius Page 418
Measure a basic rotation using a line Page 420
Set the datum in any axis Page 422
Set a corner as datum Page 423
Set the circle center as datum Page 424
Touch probe system data management Page 424
