HEIDENHAIN TNC 320 349
1
0
.9 A
ccessing T
a
bles with SQL Commands
SQL BIND
SQL BIND binds a Q parameter to a table column. The SQL commands
"Fetch," "Update" and "Insert" evaluate this binding (assignment) during
data transfer between the result set and the NC program.
An SQL BIND command without a table or column name cancels the
binding. Binding remains effective at the longest until the end of the
NC program or subprogram.
8 Parameter no. for result: Q parameter that is
bound (assigned) to the table column.
8 Database: Column name: Enter the table name and
column name separated by a period.
Table name: Synonym or path and file name of this
table. The synonym is entered directly, whereas the
path and file name are entered in single quotation
marks.
Column designation: Designation of the table
column as given in the configuration data.
Example: Bind a Q parameter to a table column
11 SQL BIND Q881 "TAB_EXAMPLE.MEAS_NO"
12 SQL BIND Q882 "TAB_EXAMPLE.MEAS_X"
13 SQL BIND Q883 "TAB_EXAMPLE.MEAS_Y"
14 SQL BIND Q884 "TAB_EXAMPLE.MEAS_Z"
Example: Cancel binding
91 SQL BIND Q881
92 SQL BIND Q882
93 SQL BIND Q883
94 SQL BIND Q884
„ You can program any number of bindings. Read and
write processes only take into account the columns that
were entered in the "Select" command.
„ SQL BIND... must be programmed before "Fetch,"
"Update" or "Insert" commands are programmed. You
can program a "Select" command without a preceding
"Bind" command.
„ If in the "Select" command you include columns for
which no binding is programmed, an error occurs during
read/write processes (program interrupt).
