HEIDENHAIN TNC 320 (340 551-01) - Manual (Page 393)

HEIDENHAIN TNC 320 393
1
1
.7 Optional Bloc
k Skip
11.7 Optional Block Skip
Function
In a test run or program run, the TNC can skip over blocks that begin
with a slash “/”:
8 To run or test the program without the blocks
preceded by a slash, set the soft key to ON.
8 To run or test the program with the blocks preceded
by a slash, set the soft key to OFF.
Inserting the “/” character
8 In the Programming and Editing mode you select the block in which
the character is to be inserted.
8 Press the SHOW BLOCK soft key
Erasing the “/” character
8 In the Programming and Editing mode you select the block in which
the character is to be erased.
8 Press the HIDE BLOCK soft key
This function does not work for TOOL DEF blocks.
After a power interruption the control returns to the most
recently selected setting.
