IMG 1010 - SD Card

Any line beginning with the # symbol is a comment and is not processed by the IMG.

Below is the information the user will edit for use in their network



yiaddr --> IP Address of the IMG being loaded



subnetmask --> Subnet mask of the IMG being loaded



giaddr --> IP Address of the Gateway connected to the IMG



file --> If using the SD card to supply boot information but loading the

software from the FTP Server; the System Software Filename on the

bootup.cfg file should be given a path to the IMG System Software file located

on the ftp server. The default path is /excelsw/ftpBuilds or ftpBuilds/ as the

IMG 1010 logs into the FTP server using the excelsw account.



Host flag --> The Host Flag informs the IMG 1010 of configuration details

such as T1 or E1, Boot from SD card or Boot from FTP Server, and a few other

configuration details. See Setting Host Flags.



siaddr --> IP Address of FTP server which provides the IMG 1010 System

Software and NTP Server information



sname --> Optional, not currently used. Do not edit this.

Change the Host Flag to "Retrieve IMG Build from SD Card".

Host Flag Values

32 = Boot from SD Card, T1 system

34 = Boot from SD Card, E1 system

Example: The following is a T1 system booting from SD Card. Refer to the file Setting

Host Flags to follow the example

Boot From SD card = 32

T1 system = add +00

Host Flag Value = 32

The Host Flag for a T1 system booting from SD Card = 32

Edit the bootup.cfg file to reflect the new Host Flag value

Edit the System Software Filename in the bootup.cfg file to reflect the new software file

being loaded. (Ex: file=/excelsw/ftpBuilds)

Edit the rest of the bootup.cfg file to reflect your network values.

Save the bootup.cfg file.

10.

Remove the SD card from the SD Writer.

11.

Insert the SD card into the SD slot on the Front Panel of the IMG.

12.

Power-up the IMG. The fans on the IMG will run at full speed while diagnostics are

running and software is being loaded

13.

The LCD screen will show the following:

While software is loading to the IMG 1010 the LCD screen will display the following

MAC: 00:20:1C:04:03:11 ID:0101

SDC Loading

After the software has loaded to the IMG 1010 the LCD screen will display the following

MAC: 00:20:1C:04:03:11 ID:0101

Load OK/Jumping to Load

After software is done loading, the LCD screen will display the node info and the fans will

slow to normal operation

Node Name: IMG1010

Node ID: 255

14.

The loading of software and configuring of network information is now complete. The IMG

1010 is now ready to be configured.
