Page 110
Installation and Setup
102
Surface Mounting - IMG 1004
Topic Location: IMG 1004-Installation and Setup Guide > IMG 1004-Hardware
Installation
Mounting Guidelines
When mounting the chassis, follow these guidelines:
Do not obstruct air flow to the front or rear vent holes on the unit.
Mount in a clean well ventilated area.
Procedure
1.
Set the unit on a clean, secure and level surface. Unit is now ready for cabling.
Next Task
IMG 1004 - Connecting AC Power
