IMG 1010 - Software Installation and Setup
77
Connections to the GCEMS server
Port # Description Purpose Connection from
TCP: 22 SSH Remote access to GCEMS
server
 Local support
personnel
 Dialogic
technical support
TCP: 5901 VNC Remote access to
GCEMS server
 Local support
personnel
 Dialogic
technical support
TCP: 80 HTTP MRTG monitoring Local support personnel
TCP: 12610 IMG
Management
Connection to IMG IMG
TCP: 2623 Remote
ClientView
Connection from Remote
Clientview to GCEMS
Remote ClientView
TCP: 2624 ClientView GUI for Configuration &
Provisioning
Local support personel
GCEMS server
Connections between IMG's if running redundant SS7 or SS7
with remote IMG’s
Port # Description Purpose Connection from
UDP:
34867
SS7
Management
Internal SS7 communication
between IMGs
PortMap Request
 PortMap uses Port 111 and is used to request a mount port. Request is sent from
 Mount uses the port returned in the PortMap response
 NFS uses port 2049
