IMG 1004 - SD Card
153
4.
Any line beginning with the # symbol is a comment and is not processed by
the IMG 1004. Below is the information the user will edit for use in its
network
yiaddr --> IP Address of the IMG 1004 being loaded
subnetmask --> Subnet mask of the IMG 1004 being loaded
giaddr -->
IP Address of the Gateway connected to the IMG 1004
file --> If using the SD card to supply boot information but
loading the software from the FTP Server, the System Software
Filename on the bootup.cfg file should be given a path to the
IMG System Software file located on the ftp server. The default
path is /excelsw/ftpBuilds or ftpBuilds/ as the IMG 1004 logs into
the FTP server using the excelsw account.
Host flag --> The Host Flag informs the IMG of configuration
details such as T1 or E1, Boot from SD card or Boot from FTP
Server, and a few other configuration details. See Setting Host
Flags.
siaddr --> IP Address of FTP server which provides the IMG
1004 System Software and NTP Server information
sname --> Optional, not currently used. Do not edit this
5.
Change the Host Flag to "Retrieve IMG Build from SD Card".
Host Flag Values
32 = Boot from SD Card, T1 system
34 = Boot from SD Card, E1 system
Example: The following is a T1 system booting from SD Card. Refer
to the file Setting Host Flags to follow the example
Boot From SD card = 32
T1 system = add +00
Host Flag Value = 32
The Host Flag for a T1 system booting from SD Card = 32
6.
Edit the bootup.cfg file to reflect the new Host Flag value
7.
Edit the System Software Filename in the bootup.cfg file to reflect the new
software file being loaded. (Ex: file=/excelsw/ftpBuilds)
8.
Edit the rest of the bootup.cfg file to reflect your network values.
9.
Save the bootup.cfg file
10.
Remove the SD card from the SD Writer.
11.
Insert the SD card into the SD slot on the Front Panel of the IMG.
12.
Power-up the IMG.
13.
The IMG 1004 will go through a diagnostic check and then load software. See
IMG 1004 - Front Panel Status LEDs for more information on the boot
process.
14.
Once the loading of software and configuring of network information is
complete, the IMG 1004 will be ready to get configured
Next Task
Starting GateControl EMS
