39
IMG 1010 - Software Installation and Setup
Software Installation and Setup - IMG 1010
Topic Location: IMG 1010-Installation and Setup Guide > IMG 1010-Software
Installation and Setup
Overview on Downloading Software to IMG 1010
The IMG 1010 can get its software load in one of a three different ways.
1. Software is loaded through use of an FTP server. The Linux Server that is setup
for use with GCEMS can also be setup to use as an FTP server. See the
procedure in this topic below
2. Software is loaded through use of an SD Card which can be inserted into the
front panel of the IMG 1010
IMG 1010 - Downloading System Software from an SD Card
3. A combination of using the SD Card and FTP Server. The SD Card is used to
assign IP and FTP addresses and the FTP server holds the files needed for the
download.
IMG 1010 - Downloading System Software Using a Boot File on an SD Card
Items Required for Installation
For a list of items required click on the link: IMG 1010-Items Required for
Installation .
Minimum Server Specifications
For a detailed explanation on minimum requirements click on link: Dell Server
Configuration Details
Before You Begin
 Verify you have unpacked, mounted, and connected power to the GCEMS server
(Linux Server) and IMG 1010. See the manufacturer's instructions for installation
procedures.
 Verify that you have acquired IP Addresses for the IMG 1010 and the GCEMS
server.
 Verify that you have the correct MAC address from the IMG 1010. The MAC
address is displayed on a label located on the bottom side of IMG 1010 chassis.
The label is positioned toward the front panel. The second way of acquiring the
MAC address is to power the unit ON. The IMG 1010 will display the MAC address
on the LCD display even when software is not loaded.
 Verify the latest IMG 1010 system software file has been acquired. This file is on
the software supplied or can be downloaded after logging in to the Dialogic
Technical Support Website. http://www.dialogic.com/support and selecting
Software Downloads BBS. (You must have login access to both the support site
and the BBS site in order to be able to download software)
 Verify the latest GCEMS software files (IMG_10.x.xxx and
IMGUserInterface_10.5.x.xxx) have been acquired. The files are located on the
software discs supplied or can be downloaded after logging in to the Dialogic
Support Website. http://www.dialogic.com/support and selecting Software
Downloads
