Installation and Setup
34
Dell Server Configuration Details
Topic Location:
IMG 1010-Installation and Setup Guide > IMG1010-Linux Red Hat Installation
- or-
IMG 1004-Installation and Setup Guide > IMG1004-Linux Red Hat Installation
NOTE:
 The Dell 860 Pentium D server in table below is to be used on
configurations with 4 or less IMG Nodes.
 The Dell 1950 server in table below is to be used on configurations from
4 to 32 IMG Nodes
 The Dell CR100 server in table below is to be used on configurations
from 4 to 32 IMG nodes. The Dell CR100 supports Red Hat Linux
Enterprise 4.0 and 5.0
 The part numbers are the base numbers of the GCEMS server and do not
include Linux Red Hat OS loaded on them.
 The IMG CR-100 server does not include a CD-ROM drive within the unit.
A USB CD-ROM drive is included in some server bundles and is also
available for purchase from Dialogic for instances when a CD-ROM drive
is required.
Server 47-0200-00 47-0202-00 47-0203-00 47-0182-01
(Going EOL)
Model Dell 860
Pentium D
Dell CR100 Dell CR100 Dell 1950
Processor 3.2 GHz
Pentium D
(935)
1.8 GHZ Dual
Core E2160
1.8 GHZ Core 2
Duo E4300
3.0 GHz (5160)
Processor
Qty
1 of 1 1 of 1 1 of 1 1 of 2
L2 Cache 4 MB 1 MB 2 MB 4 MB
Memory 1 GB DDR2,
667MHz
1 GB DDR2 2 GB DDR2 1 GB, 667 MHz
Hard Drive 80 GB SATA
(7.2 K rpm)
160GB, 3.5
SATA (7.2K
rpm)
250GB, 3.5
SATA (7.2K
rpm)
73 GB SAS, 3.5
IN, (15 K rpm)
Hard Drive
Quantity
2 1 1 2
Hard Drive
Controller
SAS5iR RAID None None PERC 5/i
Optical Drive CD None None CD 24X
Power
Supplies
1 of 1, AC 1 of 1, AC 1 of 1, AC 1 of 2, AC
Rack Mount
Kit
Included Optional Optional Optional
ROHS Yes, 5
(includes Pb
exemption)
Yes, 5 (includes
Pb exemption)
Yes, 5 (includes
Pb exemption)
Yes, 5 (includes
Pb exemption)
