C-Band Transceiver

Revision 1

CSAT-5060 5 to 25 Watt Installation

MN/CSAT5060.IOM

A–2

A.2

Single-Thread Configuration

WARNING

The Downconverter RF input connector is wired to supply DC voltage to an
LNA. This voltage is capable of damaging any test equipment connected to
the connector. Do not connect test equipment to this connector without a
coaxial DC block between the connector and the test equipment.

A.2.1

Mounting Kit

The following mounting is providing to pole-mount the unit in a single-thread
configuration. The following tables reflect the contents of the mounting kits.

Table A-1. Universal Pole Mount, AS/0599

Part No. Nomenclature

QTY

AS/0414

Kit, Universal Pole Mount

AS/0608

Bracket, Mount 25W Single Thread 1
