Comtech EF Data CSAT-5060 - Manual (Page 128)

C-Band Transceiver Revision 1
CSAT-5060 50 Watt Installation MN/CSAT5060.IOM
B–14
Item No. Part No. Nomenclature QTY
1 FP/WG0034 Waveguide Termination, Small Fins 1
2 FP/WG0043 Waveguide CPRG137, 90
° “E” 5.50 Flex x 2.00 2
3 GA/GSKTCP137FUL Gasket, CP137, Full Thick 3
4 HW/M5FLAT Washer, M5 Flat 28
5 HW/M5LOCK Lockwasher, M5 SS, Metric 28
6 HW/M5X.08X12MMHEX Bolt, M5X.08X12MM Hexhead SS 28
7 SW/WG3AGSM Switch, CPR137G, +24V, Sealed Metric 1
Figure B-12 . Waveguide Switch, TX 1:1, AS/0462
