C-Band Transceiver Revision 1
CSAT-5060 5 to 25 Watt Installation MN/CSAT5060.IOM
A–10
Item
No.
Part No. Nomenclature QTY KT/9676-1 KT/9676-2
2 FP/BR0073 Bracket, Spar 1.00 x 2.00 2 X
-2A FP/BR9776-1 Bracket, Spar 2.5 x 2.5 2 X
3 FP/BR0095 Bracket, Single-Thread 1 X X
4 HW/M8FLATSS Washer, Flat, M8 SS, Metric 8 X X
5 HW/M8LOCKSS Washer, Splitlock, M8, SS, Metric 4 X X
6 HW/M8X1.25HEXNUTSS Nut, Hex M8 x 1.25, SS, Metric 4 X X
7 HW/M8X1.25X15MMHEX Bolt, Hex Head, M8 X 1.25 x 15 MM,
SS
4 X X
8 HW/M8X1.25X30MMFHS Screw, Flathead, M8X1.25X30MM,
SS, 90
°
4 X X
- Item not illustrated.
Figure A-11. SPAR Mount Kit, KT/9676-1 or KT/9676-2
