Comtech EF Data CSAT-5060 - Manual (Page 65)

C-Band Transceiver Revision 1
Remote Control MN/CSAT5060.IOM
6-13
Parameter
Type
Command
(Instruction
Code and
qualifier)
Arguments
for
Command
or
Response
to Query
Description of arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Slave to Master)
Query
(Instruction
code and
qualifier) Response to query
(Slave to Master)
Set RTC
Time TIM= 6 bytes,
numerical
A command in the form hhmmss, indicating the time
from midnight, where hh = hours, between 00 and 23;
mm = minutes, between 00 and 59, and ss = seconds,
between 00 and 59
Example: TIM=231259 would be 23 hours, 12 minutes
and 59 seconds from midnight.
TIM= (message ok)
TIM? (received ok,
but invalid
arguments found)
TIM* (message ok,
but not permitted in
current mode
TIM? TIM=xxxxxx
(same format as command
arguments
Clear All
Stored
Alarms CAA= None Command only
Instructs the slave to clear all Stored Events
This command takes no arguments.
CAA= (message ok) N/A N/A
Re-Initialize
Retrieved
Alarms Point IAP= None Command only
Instructs the unit to zero the retrieved alarms pointer to
allow the user to retrieve the complete stored alarms
log.
IAP=(message ok) N/A N/A
List New
Alarms
(Retrieve
next 5
unread
Stored
Alarms) N/A 145 bytes Query only
CSAT returns the oldest 5 Stored Events that have not
yet been read over the remote control. Reply format:
Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body, where Sub-body=
YYYYYYYYYY ZZ hhmmss,mmddyy
YYYYYYYYYY being the fault description.
ZZ being the alarm type.
FT = Fault
OK = Clear
IF = Information
If there are no new events, the CSAT will reply with
LNA*. Note: the CSAT incorporates a circular buffer
capable of holding 100 events/alarms.
N/A LNA? LNA=YY..ss
(see description for details of
arguments)
