Comtech EF Data CSAT-5060 User Manual
Page 126
C-Band Transceiver
Revision 1
CSAT-5060 50 Watt Installation
MN/CSAT5060.IOM
B–12
Item
Part No.
Nomenclature
QTY
1 CA/RF0097
Cable,
Output
RF
4
2
CA/WR0051
Cable, Control-LNA Switch
1
3
CA/WR0052
Cable, Control-TX Switch
1
4 CA/WR0053
Cable,
Communication
1
5 CA/WR0053
Cable,
Communication
1
Figure B-10
. Cable Kit
