C-Band Transceiver

Revision 1

CSAT-5060 50 Watt Installation

MN/CSAT5060.IOM

B–10

B.5

Redundancy Configuration

B.5.1

Mounting Kit


Table B-2. Final 1:1, C-Band Assembly

Part No.

Nomenclature

QTY

AS/0438

Kit, LNA Mounting

1

AS/0460

Kit, Waveguide CPR137G

1

AS/0461

Kit, Waveguide CPR229

1

AS/0462

Switch, Waveguide, TX 1:1

1

AS/0490

Assy, Remote Switch Box

1


Table B-3. 1:1 Mounting Assembly, AS/0597

Part No.

Nomenclature

QTY

*AS/0414

Redundancy Kit, Pole Mount

2

*AS/0415 Single-Thread

Mounting

Kit

2

AS/0437

Switch, Mount Kit TX

1


IMPORTANT

*Refer to Single-Thread Configuration.
