C-Band Transceiver

Revision 1

CSAT-5060 100/125 Watt Installation MN/CSAT5060.IOM

C–12












Note: For mounting customer-supplied unit to Transmit Switch Assembly

Item No.

Part No.

Nomenclature

QTY

1

HW/M5X.08X30MMHEX

Bolt, M5X.08X30MM Hexhead SS

12

2 GA/GSKTCP137HLF Gasket,

CP137, Half Thick

1

3

HW/M5X.08HEXNUT

Nut, Hex M5 x .08 SS

12

4 HW/M5LOCK

Lockwasher, M5 SS, Metric

12

5

GA/GSKTCP137FUL

Gasket, CP137, Full Thick

1

6

HW/M5FLAT

Washer, M5 Flat

24

Figure C-10. Waveguide Kit, CPR137G, AS/0460
