C-Band Transceiver Revision 1
Connector Pinouts MN/CSAT5060.IOM
3–2
3.1.2 Connector J5: COMM, Remote communications port
Mating connector: ITT: KPT06J14-19P or MS3116J14-19P
Connections, refer to the following table:
Pin Signal I/O Notes
A RS-485 +RX Input CSAT Receive Line
B RS-485 –RX Input CSAT Receive Line Complement
C RS-485 TX+ Output CSAT Transmit Line
D RS-485 TX- Output CSAT Transmit Line Complement
E RS-232 Rd Input CSAT Receive Line
F REDUNDANT FAULT Input Redundant Controller Status Input
G RS-232 Td Output CSAT Transmit Line
H AUXCOM Rd Input Auxiliary RS232 Rd used with Redundant Controller
J AUXCOM Td Output Auxiliary RS232 Td used with Redundant Controller
K FAULT COMMON Output
L FAULT NORM OPEN Output Open (OK) / Short (Fault)
M FAULT NORM CLOSED Output Short (OK) / Open (Fault)
N ADDRESS SELECT Input Redundant Addressing
P ONLINE STATUS Input Input from Redundant Controller
R +24V AUX Output 24V output to power Redundant Controller
S REDUNDANCY Input Open (stand-alone) / Gnd (Redundancy)
T GROUND Passive
U GROUND Passive
V NO CONNECT
