CSAT-5060 C-Band Transciever Revision 1
+10 dBm Model C-Band Transceiver MN/CSAT5060.IOM
9–4
Common Environmental
Conversion Dual, No Spectral Inversion Temperature:
Operating
Non-Operating
-40 to +55
°C (-40 to 131°F)
-50 to +75
°C (-58 to 167°F)
Sense Positive, No Inversion Attitude 15,000 Feet,
mean sea level
Frequency
Step Size 1 and 2.5 MHz automatic Humidity 0 to 100 %, Relative
Frequency
Stability ± 1 x 10 -9 /day (maximum)
1 x 10
-7
/day
± 1 x 10 -8
/day (maximum)
-40 to 55
°C (-40 to 131°F)
Rainfall 50 mm/hr
Attentuation
Steps TX
TX (Optional)
RX
RX (Optional) 0 to 25 dB, in 0.25 dB steps
0 to 30 dB, in 0.25 dB steps
0 to 20 dB, in 0.25 dB steps
0 to 30 dB, in 0.25 dB steps Solar Radiation 350 BTU/foot2/hour
Phase Noise 100 Hz
1 kHz
10 kHz
100 kHz -66 dBc/Hz
-76 dBc/Hz
-86 dBc/Hz
-96 dBc/Hz Prime Power 90 to 260 VAC Standard
47 to 63 Hz Standard
48 VDC Optional
Group Delay Linear
Parabolic
Ripple 0.1 ns/MHz
0.02 ns/MHz
2
1 ns/p-p
M&C Methods Both EIA-485 and EIA-232 Serial Interface
Handheld controller, optional
External
Reference
Connector 5 or 10 MHz EXT REF port available in
addition to internal frequency reference.
Redundant
Switch Outdoor unit (ODU) with autoswitch on
failure
M&C Interface M&C Interfaces between:
Transceivers and Switch
Switch and CMA compler
MTBF:
Transceiver
Switch
≥ 50,000 hours
≥ 90,000 hours
CE Mark Meets CE Mark spec
