C-Band Transceiver Revision 1
CSAT-5060 100/125 Watt Installation MN/CSAT5060.IOM
C–4
Item No. Part No. Nomenclature QTY
1 FP/BR0067 Bracket, Pole Mount Kit 2
2 HW/M8FLATSS Washer, Flat, M8 SS, Metric 8
3 HW/M8LOCKSS Washer, Splitlock, M8, SS, Metric 8
4 HW/M8SPRINGNUT Springnut, M8 xX 1.25 4
5 HW/M8X1.25MMHEXSS Bolt, Hex M8X1.25X16MM, SS 4
6 HW/M8X1.25X25HEXSS Bolt, Hexhead, M8X1.25X25, SS 4
Figure C-2. CSAT Mounting Brackets, AS/0415
