Comtech EF Data CSAT-5060 User Manual
Page 105
C-Band Transceiver
Revision 1
CSAT-5060 5 to 25 Watt Installation
MN/CSAT5060.IOM
A–15
Item
Part No.
Nomenclature
QTY
1
CA/RF0097
Cable, Output RF
4
2
CA/WR0051
Cable, Control-LNA Switch
1
3 CA/WR0052 Cable, Control-
TX
Switch
1
4 CA/WR0053 Cable,
Communication
1
5 CA/WR0053 Cable,
Communication
1
Figure A-16. Cable Kit, AS/0440
