CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–10
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
TX Gain Offset UGO= 5 bytes
numerical
Command or Query.
TX Gain Offset for 1:1 redundancy configurations.
In dB, between -0.00 and -4.00. Resolution = 00.25 dB.
Example: UGO=-1.25
UGO= (message ok)
UGO? (received ok, but
invalid arguments found)
UGO? UGO=xx.xx
See Note 1
RX Gain Offset DGO= 5 bytes
numerical
Command or Query.
RX Gain Offset for 1:1 redundancy configurations.
In dB, between -0.00 and -4.00. Resolution = 00.25 dB.
Example: DGO=-1.25
DGO= (message ok)
DGO? (received ok, but
invalid arguments found)
DGO? DGO=xx.xx
See Note 1
TX Amplifier AMP= 1 byte,
value of 0,1
Command or Query.
TX Amplifier, where:
0 = Amplifier OFF
1 = Amplifier ON
Example: AMP=1
AMP= (message ok)
AMP? (received ok, but
invalid argument found)
AMP? AMP=x
See Note 1
Mute Mode MUT= 1 byte,
value of 0,1
Command or Query.
Mute Mode, where:
0 = Unmuted after Frequency change,
1 = Muted after Frequency change.
Example: MUT=1
MUT=(message ok)
MUT?(received ok, but
invalid argument found)
MUT? MUT=x
See Note 1
TX Mute UMU= 1 byte,
value of 0,1
Command or Query.
TX Mute, where:
0 = Transmitter Unmuted,
1 = Transmitter Muted
Example: UMU=1
UMU=(message ok)
UMU?(received ok, but
invalid argument found)
UMU? UMU=x
See Note 1
RX Mute DMU= 1 byte,
value of 0,1
Command or Query.
RX Mute, where:
0 = Receiver Unmuted,
1 = Receiver Muted
Example: DMU=1
DMU=(message ok)
DMU?(received ok, but
invalid argument found)
DMU? DMU=x
See Note 1
TX Slope Mode USM= 1 byte,
value of 0,1
Command or Query.
TX Slope Mode, where:
0 =Manual Mode,
1 = Calibrated Mode.
Example: USM=1
USM=(message ok)
USM?(received ok, But
invalid argument found)
USM? USM=x
See Note 1
