Comtech EF Data CSAT-5060 - Manual (Page 59)

C-Band Transceiver Revision 1
Remote Control MN/CSAT5060.IOM
6-7
Parameter
Type
Command
(Instruction
Code and
qualifier)
Arguments
for
Command
or
Response
to Query
Description of arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Slave to Master)
Query
(Instruction
code and
qualifier) Response to query
(Slave to Master)
TX
Frequency UFQ= 6 bytes
numerical Command or Query.
TX Frequency in valid range.
Frequency divisible by 1MHz and 2.5 MHz are allowed.
Example: UFQ= 5901.0
UFQ= (message ok)
UFQ? (received ok,
but invalid
arguments found)
UFQ? UFQ=xxxx.x (same format as
command arguments)
RX
Frequency DFQ= 6 bytes
numerical Command or Query.
RX Frequency in valid range.
Frequency divisible by 1MHz and 2.5 MHz are allowed.
Example: DFQ=3652.5
DFQ= (message ok)
DFQ? (received ok,
but invalid
arguments found)
DFQ? DFQ=xxxx.x (same format as
command arguments)
TX
Attenuation UAT= 5 bytes
numerical Command or Query.
TX Attenuation, in dB, between 00.00 and 25.00.
Resolution = 00.25 dB.
Example: UAT=12.75
UAT= (message ok)
UAT? (received ok,
but invalid
arguments found)
UAT? UAT=xx.xx
(same format as command
arguments)
RX
Attenuation DAT= 5 bytes
numerical Command or Query.
RX Attenuation, in dB, between 00.00 and 20.00.
Resolution = 00.25 dB.
Example: DAT=12.75
DAT= (message ok)
DAT? (received ok,
but invalid
arguments found)
DAT? DAT=xx.xx
(same format as command
arguments)
TX Gain
Offset UGO= 5 bytes
numerical Command or Query.
TX Gain Offset for 1:1 redundancy configurations.
In dB, between -0.00 and -4.00. Resolution = 00.25 dB.
Example: UGO=-1.25
UGO= (message ok)
UGO? (received ok,
but invalid
arguments found)
UGO? UGO=xx.xx
(same format as command
arguments)
RX Gain
Offset DGO= 5 bytes
numerical Command or Query.
RX Gain Offset for 1:1 redundancy configurations.
In dB, between -0.00 and -4.00. Resolution = 00.25 dB.
Example: DGO=-1.25
DGO= (message ok)
DGO? (received ok,
but invalid
arguments found)
DGO? DGO=xx.xx
(same format as command
arguments)
TX Amplifier AMP= 1 byte,
value of
0,1 Command or Query.
TX Amplifier, where:
0 = Amplifier OFF
1 = Amplifier ON
Example: AMP=1
AMP= (message ok)
AMP? (received ok,
but invalid argument
found)
AMP? AMP=x
(same format as command
argument)
