Hardware Preparation and Installation
ATCA-7370/ATCA-7370-S Installation and Use (6806800P54H) 51
2. Temperature Spot 2 (on 48V/12V DC/DC Module) Max: 100°C (exact location: in the
geometric middle of the heat spreader)
2.2.2 Power Requirements
The blade's power requirements depend on the installed hardware accessories. If you want to
install accessories on the blade, the load of the respective accessory must be added to that of
the blade. In
Table 2-2 , you will find typical examples of power requirements with and without
accessories installed.For information on the accessories' power requirements, refer to the
documentation delivered together with the respective accessory or consult your local Artesyn
Embedded Technologies representative for further details.
The blade must be connected to a TNV-2 or a safety-extra-low-voltage (SELV) circuit. A TNV-2
circuit is a circuit whose normal operating voltages exceed the limits for a SELV circuit under
normal operating conditions, and which is not subject to over voltages from
telecommunication networks.
Table 2-2 Power Requirements
Characteristic Value
Rated Voltage
Exception in the US and Canada -48 VDC to -60 VDC
-48 VDC
Operating Voltage
Exception in the US and Canada -39 VDC to -72 VDC
-39 VDC to -60 VDC
Max. power consumption of ATCA-7370
(with ATCA-7370-ACC-Module and with RTM-ATCA-
737x including two SAS HDDs) 260W (typ. 220W)
Max. power consumption of ATCA-7370
(without ATCA-7370-ACC-Module and without RTM) 220W (typ. 180W)
Max. power consumption of ATCA-7370-s (without
ATCA-7370-ACCEL-MOD and without RTM) 140W (typ. 120W)
