Form I-PDH/SDH/PEH/SHH/PXH, Page 68
Wiring Diagram
Option Identification
The Option Codes for these electrical options are shown on the wiring diagram. Only
options ordered with be listed on the custom wiring diagram.
Option
Code
Brief Description
AG1 Analog Heating Control - 1-Stage
AG2 Analog Heating Control - 2-Stage
AG3 Analog Heating/Makeup Air - 2-Stage unit-mounted ductstat
AG15 Analog Heating/Makeup Air - 2-Stage remote ductstat w/dial
AG16 Analog Heating/Makeup Air - same as AG15 with display
AG40 Analog Heating/Makeup Air - converts to digital for field supplied BMS
AG58 Analog Heating/Makeup Air - electronic modulation 8:1 turndown (SHH)
AG60 Analog Heating/Makeup Air - same as AG3 plus 33% low fire
AG61 Analog Heating/Makeup Air - same as AG15 plus 33% low fire
AG62 Analog Heating/Makeup Air - same as AG61 with display
AK1 115/1 Supply Voltage
AK2 208/1 Supply Voltage
AK3 230/1 Supply Voltage
AK5 208/3 Supply Voltage
AK6 230/3 Supply Voltage
AK7 460/3 Supply Voltage
AK8 575/3 Supply Voltage
AN2 Contactor, IEC
AN10 Motor Starter with Overloads
AR8 On/Off Inlet Air Damper with Duct Flanges
AU7 Cooling Coil Cabinet with DX Coil and Reheat Pump
AUR1 Modulating Reheat
BA6 Disconnect Switch - Flush-mounted, lockable, non-fusible
BB8 Wiring for Energy Recovery Module
BC2 Convenience Outlet (requires separate power supply)
BD4 Firestat, 200°F
BD5 Firestat, 200°F (field installed)
BE2 Low Limit, Discharge Temperature
BE4 Evaporator Frostat for Coils
BF14 Phase Loss/Low Voltage Protection - with AK5, AK6, AK7 only
BF15 Phase Loss/Phase Reversal Protection - 3 phase only
BG7__ Plugin DPDT Relay - Specified operation
BG9 Plugin DPDT Relay - Exhaust Fan Interlock
BHB1 Time Clock Card - with DG 1, 2, 5, 6
BHB2 N2 Card - with DG 1, 2, 5, 6 and D12 B, C, D, E
BHB3 LonMark Card - with DG 1, 2, 5, 6 and D12 B, C, D, E
BN2 Limit Control - High Ambient (burner cutoff)
BP4 Gas Pressure Safety Switches, High and Low
CL1 Thermostat - 1-stage heat, 24V, 40-80°F
CL22 Thermostat - 24v non programmable, 1 or 2-stage
CL23 Thermostat - 24v, 2-stg heat/cool, touch screen, programmable
CL33 Thermostat - 2-stage heat/cool, 24V, programmable
CL36 Thermostat - Modulating Heat/cool with 3-stage cooling
CL52 Thermostat - 1-stage heat/cool, 24V, 45-88°F, programmable 5/2 day
CL67 Space Temperature Sensor/Override - with D12 B, C, D, E
CN1__ 3-Position Switch - specified operation
CN3__ 2-Position Switch - specified operation
CP__ Disconnect Switch (field installed)
CT1 Evap Cooler Fill & Drain Kit - 120/1 with AK1, AK7, AK8
CT2 Evap Cooler Fill & Drain Kit - 208/1 with AK2, AK5
CT3 Evap Cooler Fill & Drain Kit - 240/1 with AK3, AK6
CT5 Evap Cooler Freeze Protection - AquaSaver controls
CT6 Evap Cooler Freeze Protection - with CT 1, 2, or 3
Option
Code
Brief Description
D12B
Digital Control w/FX06 - Neutral Air/Discharge Air Temp Control (applies
to PDH or SDH with or without reheat)
D12C
Digital Control w/FX06 - Space Temp Cntrl w/Discharge Air Reset
(applies to SDH or PDH with or without reheat)
D12D
Digital Control w/FX06 - Neutral Air/Discharge Air Temp Control (applies
to PEH with SCR (modulating) heating control and 3-stage cooling with
or without reheat)
D12E
Digital Control w/FX06 - Recirculating Air Temp Control (applies to PEH
with 2-stage heating and 3-stage cooling with or without reheat) (not
recommended for makeup air)
D12F
Digital Control w/FX06 - Space Temperature, 2-stage heating / 3-stage
cooling (applies to SHH)
D12G
Digital Control w/FX06 - Gas-fired electronic modulation with 8:1 turn-
down; 3-stage cooling; with or without reheat; discharge air temperature
control (applies to SHH)
DG1
Digital Control w/FX05 - Space Temperature, 2-stg heating/3-stg cool-
ing (applies to PDH or SDH without reheat)
DG2
Digital Control w/FX05 - Space Temperature elec mod htg/3-stg clng
(applies to PDH or SDH without reheat)
DG5
Digital Control w/FX05 - Discharge Air Temperature, 2-stg htg/3-stg clng
(applies to PDH or SDH without reheat)
DG6
Digital Control w/FX05 - Discharge Air Temperature elec mod htg/3 stg
clng (applies to PDH or SDH without reheat)
ECD1 Evap Cooler AquaSaver meter water flow system
ECD2 Evap Cooler Recirculating Pump Control
EG1 Analog Heating Control - 1 Stage thermostat (PEH)
EG2 Analog Heating Control - 2 Stage thermostat (PEH)
GE3 Damper Control - Outside air, 2-position motor
GE5 Damper Control - Outside air, 3-position motor
GE6 Damper Control - Outside & Return, 2-position motor
GE7 Damper Control - Outside & Return, 2-position mtr w/warm up
GE8 Damper Control - Outside & Return, 3-position, unit potentiometer
GE10 Damper Control - Outside & Return, 3-position, remote potentiometer
GE11 Damper Control - Outside & Return, modulating, mixed air
GE12 Damper Control - Outside & Return, modulating, mixed air w/min
GE13 Damper Control - Outside & Return, modulating, mixed air w/warm up
GE14 Damper Control - Outside & Return, mod, mixed air w/min & warm up
GE15 Damper Control - Outside & Return, modulating, building pressure
GE16 Damper Control - Outside & Return, modulating, BMS control
GE21 Damper Control - Outside & Return, modulating, enthalpy
GE22 Damper Cntrl - Outside & Return, modulating, dual reference enthalpy
RB2A Remote Display - Control Options D12B-G
RC__ Remote Console - lights, switches, optional sensors
SA1 Duct Photoelectric Smoke Detector
T4 XX Thermal Expansion Valve (R410A only)
UV2 Germicidal Lamp
VFD1 Variable Frequency Drive
VFD2 Variable Frequency Drive (requires field installation)
VFD3 Variable Freuency Drive (supplied by others)
APPENDIX (cont’d)
