Form I-PDH/SDH/PEH/SHH/PXH, Page 4
All Reznor ® units must be installed in accordance with local building codes. In the
absence of local codes, in the United States, Model PDH, SDH, and SHH units must be
installed in accordance with the National Fuel Gas Code NFPA54/ANSI Z223.1 (latest
edition). A Canadian installation must be in accordance with the CSA B149.1 Natural
Gas and Propane Installation Code. Both codes are available from CSA Information
Services, 1-800-463-6727. All packaged systems must be installed in compliance with
the National Electric Code ANSI/NFPA No. 70 (latest edition) or in the Canada, the
Canadian Electrical Code Part I-C.S.A. Standard C22.1. Local authorities having juris-
diction should be consulted before installation is made to verify local codes and instal-
lation procedure requirements.
Special Installations (Aircraft Hangars/Garages) - In the United States, instal-
lation in an aircraft hangar should be in accordance with NFPA No. 409 (latest edition),
Standard for Aircraft Hangars; in parking structures in accordance with NFPA No. 88A
(latest edition); and in repair garages in accordance with NFPA 88B (latest edition). In
Canada, installations in aircraft hangars, parking garages, and repair garages should
be in accordance with the requirements of the enforcing authorities and with CSA
B149.1 codes.
Commercial Makeup Air Installations - Gas-fired Models PDH, SDH, and SHH
are certified by ANSI Z83 family of standards governing the safe usage of heating
equipment in the industrial/commercial marketplace. This includes using the heaters
in makeup air applications to supply corridor pressurization in commercial buildings
such as office structures and apartment complexes. This product may be used for all
makeup air applications except one or two family dwellings.
Gas-fired Models
PDH, SDH, and SHH
1.5 Installation
Codes
1.3 General
Installation
Information
(cont’d)
Option D12B, D12C, D12D, D12E, D12F, or D12G using a Model FX06 digital control-
ler require Form CP-PREEVA-D12, P/N 235267. The control manual is shipped in the
literature bag with this installation manual. NOTE: If the unit has special controls and
additional information is needed, contact your distributor or the factory. Control options
are identified on the unit wiring diagram.
1.3.3 Separated-Combustion Models SDH and SHH
Models SDH and SHH are designed and manufactured in accordance with the ANSI
definition of separated combustion. That definition reads, “Separated Combustion Sys-
tem Appliance: A system consisting of an appliance and a vent cap supplied by the
manufacturer, and (1) combustion air connections between the appliance and the out-
side atmosphere, and (2) flue gas connections between the appliance and vent cap,
of a type(s) specified by the manufacturer but supplied by the installer, constructed so
that, when installed in accordance with the manufacturer’s instructions, air for com-
bustion is obtained from the outside atmosphere and flue gases are discharged to the
outside atmosphere.”
Model SDH and SHH separated-combustion units are designed to separate air for
combustion and flue products from the environment of the building in which the unit is
installed. Separated-combustion appliances are recommended for use in dust laden
and some corrosive fume environments or in buildings with negative pressure (up
to .15” w.c.). As the definition states, all separated-combustion equipment must be
equipped with both combustion air and exhaust piping to the outdoors.
1.4 Warranty Refer to the limited warranty information on the Warranty Form in the “Literature Bag”.
Warranty is void if ...
a. Heaters are used in atmospheres containing flammable vapors or atmospheres
containing chlorinated or halogenated hydrocarbons or any contaminant (silicone,
aluminum oxide, etc.) that adheres to the spark ignition flame sensing probe.
b. Wiring is not in accordance with the diagram furnished with the system.
c. Unit is installed without proper clearance to combustible materials or without
proper ventilation and air for combustion.
d. Air throughput is not adjusted within the range specified on the rating plate.
e. Product is not installed in accordance with these instructions and/or local codes.
