Reznor SHH (Indoor PreevA) Unit Installation Manual - Manual (Page 19)

Form I-PDH/SDH/PEH/SHH/PXH, Page 19
(Does NOT apply to
AG58 or D12G; see
NOTE on page 16.)
TABLE 11B - BTUH
Inputs and Capacities
by Altitude for Model
SHH with Control
Option AG1, AG2, AG3,
AG15, AG16, or D12F
BTUH Inputs and Capacities by Altitude in the UNITED STATES for Model SHH
ALTITUDE SHH130 SHH 180 SHH 260 SHH 350
Feet Meters
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
0 - 2000 0 - 610 131000 120520 175000 159,250 260,000 236,600 345,000 313,950
2001 - 3000 611 - 915 123140 113289 164500 149,695 244,400 222,404 324,300 295,113
3001 - 4000 916 - 1220 120520 110878 161000 146,510 239,200 217,672 317,400 288,834
4001- 5000 1221 - 1525 117900 108468 157500 143,325 234,000 212,940 310,500 282,555
5001 - 6000 1526 - 1830 115280 106058 154000 140,140 228,800 208,208 303,600 276,276
6001 - 7000 1831 - 2135 112660 103647 150500 136,955 223,600 203,476 296,700 269,997
7001 - 8000 2136 - 2440 110040 101237 147000 133,770 218,400 198,744 289,800 263,718
8001 - 9000 2441 - 2745 107420 98826 143500 130,585 213,200 194,012 282,900 257,439
9001 - 10000 2746 - 3045 104800 96416 140000 127,400 208,000 189,280 276,000 251,160
BTUH Inputs and Capacities by Altitude in CANADA for Model SHH
ALTITUDE SHH130 SHH 180 SHH 260 SHH 350
Feet Meters
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
Normal Input
(BTU/HR)
Thermal Output
Capacity (BTU/HR)
0 - 2000 0 - 610 131000 120520 175000 159,250 260,000 236,600 345,000 313,950
2001 - 4500 611 - 1373 117900 108468 157500 143,325 234,000 212,940 310,500 282,555
6.1.4 Optional Gas
Pressure Safety
Switches
If the manifold is equipped with optional high and/or low gas pressure switches, the
switches protect against an upstream gas control malfunction that would cause an
increase or decrease in the regulated gas pressure.
The low gas pressure switch is an automatic reset switch that is factory set to activate
if the gas pressure is 50% of the minimum as stated on the unit rating plate.
The high gas pressure switch is a manually reset switch that is set to activate if the gas
pressure is 125% of the outlet pressure stated on the rating plate.
6.2 Gas Heat
Section
Condensate
Drain(s)
A Model SHH heat section has a condensate drain connection on the secondary heat
exchanger and a burner condensate drain connection. Models PDH and SDH have a
burner condensate drain connection if ordered with Option CS2.
Follow the requirements in this section that apply to the installation. Connect all required
drain lines and install traps as illustrated. Fill traps with water. Empty the condensate
drains into a sanitary drain system. Drains may be joined downstream from the traps.
Periodic cleaning of the condensate drain pans, traps, and piping is required. If a drain
has a cleanout opening, be sure to close the opening after cleaning.
BTUH Inputs and Capacities by Altitude in the UNITED STATES for Model PDH and Model SDH
ALTITUDE
Normal
Input
Thermal
Output
Capacity
2-Stage
Minimum
Input
(applies to
AG2, AG3,
AG15,
AG16)
2-Stage with Venter
Motor Controller
Minimum Input
(applies to AG60,
AG61, AG62, DG1,
DG5, D12C)
Modulation
Minimum Input
(applies to Options
AG8, AG9, AG9H,
AG40, DG2, DG6,
D12B)
Normal
Input
Thermal
Output
Capacity
2-Stage
Minimum
Input
(applies
to AG2,
AG3, AG15,
AG16)
2-Stage with Venter
Motor Controller
Minimum Input
(applies to AG60,
AG61, AG62, DG1,
DG5, D12C)
Modulation
Minimum Input
(applies to Options
AG8, AG9, AG9H,
AG40, DG2, DG6,
D12B)
Normal
Input
Thermal
Output
Capacity
2-Stage
Minimum
Input
(applies to
AG2, AG3,
AG15,
AG16)
2-Stage with Venter
Motor Controller
Minimum Input
(applies to AG60,
AG61, AG62, DG1,
DG5, D12C)
Modulation
Minimum Input
(applies to Options
AG8, AG9, AG9H,
AG40, DG2, DG6,
D12B)
Natural Propane Natural Propane Natural Propane Natural Propane Natural Propane Natural Propane
Feet Meters Size 225 Size 250 Size 300
0-2000 0-610 225,000 182,250 157,500 74,250 90,000 56,250 90,000 250,000 202,500 175,000 82,500 100,000 62,500 100,000 300,000 243,000 210,000 99,000 120,000 75,000 120,000
2001-3000 611-915 211,500 171,315 148,050 69,795 84,600 52,875 84,600 235,000 190,350 164,500 77,550 94,000 58,750 94,000 282,000 228,420 197,400 93,060 112,800 70,500 112,800
3001-4000 916-1220 207,000 167,670 144,900 68,310 82,800 51,750 82,800 230,000 186,300 161,000 75,900 92,000 57,500 92,000 276,000 223,560 193,200 91,080 110,400 69,000 110,400
4001-5000 1221-1525 202,500 164,025 141,750 66,825 81,000 50,625 81,000 225,000 182,250 157,500 74,250 90,000 56,250 90,000 270,000 218,700 189,000 89,100 108,000 67,500 108,000
5001-6000 1526-1830 198,000 160,380 138,600 65,340 79,200 49,500 79,200 220,000 178,200 154,000 72,600 88,000 55,000 88,000 264,000 213,840 184,800 87,120 105,600 66,000 105,600
6001-7000 1831-2135 193,500 156,735 135,450 63,855 77,400 48,375 77,400 215,000 174,150 150,500 70,950 86,000 53,750 86,000 258,000 208,980 180,600 85,140 103,200 64,500 103,200
7001-8000 2136-2440 189,000 153,090 132,300 62,370 75,600 47,250 75,600 210,000 170,100 147,000 69,300 84,000 52,500 84,000 252,000 204,120 176,400 83,160 100,800 63,000 100,800
8001-9000 2441-2745 184,500 149,445 129,150 60,885 73,800 46,125 73,800 205,000 166,050 143,500 67,650 82,000 51,250 82,000 246,000 199,260 172,200 81,180 98,400 61,500 98,400
Feet Meters Size 350 Size 400A
0-2000 0-610 350,000 283,500 245,000 115,500 140,000 87,500 140,000 400,000 324,000 280,000 132,000 160,000 100,000 160,000
2001-3000 611-915 329,000 266,490 230,300 108,570 131,600 82,250 131,600 376,000 304,560 263,200 124,080 150,400 94,000 150,400
3001-4000 916-1220 322,000 260,820 225,400 106,260 128,800 80,500 128,800 368,000 298,080 257,600 121,440 147,200 92,000 147,200
4001-5000 1221-1525 315,000 255,150 220,500 103,950 126,000 78,750 126,000 360,000 291,600 252,000 118,800 144,000 90,000 144,000
5001-6000 1526-1830 308,000 249,480 215,600 101,640 123,200 77,000 123,200 352,000 285,120 246,400 116,160 140,800 88,000 140,800
6001-7000 1831-2135 301,000 243,810 210,700 99,330 120,400 75,250 120,400 344,000 278,640 240,800 113,520 137,600 86,000 137,600
7001-8000 2136-2440 294,000 238,140 205,800 97,020 117,600 73,500 117,600 336,000 272,160 235,200 110,880 134,400 84,000 134,400
8001-9000 2441-2745 287,000 232,470 200,900 94,710 114,800 71,750 114,800 328,000 265,680 229,600 108,240 131,200 82,000 131,200
BTUH Inputs and Capacities by Altitude in CANADA for Model PDH and SDH
ALTITUDE
Normal
Input
Thermal
Output
Capacity
2-Stage
Minimum
Input (applies
to AG2,
AG3, AG15,
AG16)
2-Stage with Venter
Motor Controller
Minimum Input
(applies to AG60,
AG61, AG62, DG1,
DG5, D12C)
Modulation
Minimum Input
(applies to Options
AG8, AG9, AG9H,
AG40, DG2, DG6,
D12B)
Normal
Input
Thermal
Output
Capacity
2-Stage
Minimum
Input (applies
to AG2,
AG3, AG15,
AG16)
2-Stage with Venter
Motor Controller
Minimum Input
(applies to AG60,
AG61, AG62, DG1,
DG5, D12C)
Modulation
Minimum Input
(applies to Options
AG8, AG9, AG9H,
AG40, DG2, DG6,
D12B)
Normal
Input
Thermal
Output
Capacity
2-Stage
Minimum
Input
(applies to
AG2, AG3,
AG15,
AG16)
2-Stage with Venter
Motor Controller
Minimum Input
(applies to AG60,
AG61, AG62, DG1,
DG5, D12C)
Modulation
Minimum Input
(applies to Options
AG8, AG9, AG9H,
AG40, DG2, DG6,
D12B)
Natural Propane Natural Propane Natural Propane Natural Propane Natural Propane Natural Propane
Feet Meters Size 75 Size 100 Size 125
0-2000 0-610 75,000 60,750 52,500 24,750 30,000 18,750 30,000 100,000 81,000 70,000 33,000 40,000 25,000 40,000 125,000 101,250 87,500 41,250 50,000 31,250 50,000
2001-4500 611-1373 67,500 54,675 47,250 22,275 27,000 16,875 27,000 90,000 72,900 63,000 29,700 36,000 22,500 36,000 112,500 91,125 78,750 37,125 45,000 28,125 45,000
Feet Meters Size 150 Size 175 Size 200
0-2000 0-610 150,000 121,500 105,000 49,500 60,000 37,500 60,000 175,000 141,750 122,500 57,750 70,000 43,750 70,000 200,000 162,000 140,000 66,000 80,000 50,000 80,000
2001-4500 611-1373 135,000 109,350 94,500 44,550 54,000 33,750 54,000 157,500 127,575 110,250 51,975 63,000 39,375 63,000 180,000 145,800 126,000 59,400 72,000 45,000 72,000
Feet Meters Size 225 Size 250 Size 300
0-2000 0-610 225,000 182,250 157,500 74,250 90,000 56,250 90,000 250,000 202,500 175,000 82,500 100,000 62,500 100,000 300,000 243,000 210,000 99,000 120,000 75,000 120,000
2001-4500 611-1373 202,500 164,025 141,750 66,825 81,000 50,625 81,000 225,000 182,250 157,500 74,250 90,000 56,250 90,000 270,000 218,700 189,000 89,100 108,000 67,500 108,000
Feet Meters Size 350 Size 400A
0-2000 0-610 350,000 283,500 245,000 115,500 140,000 87,500 140,000 400,000 324,000 280,000 132,000 160,000 100,000 160,000
2001-4500 611-1373 315,000 255,150 220,500 103,950 126,000 78,750 126,000 360,000 291,600 252,000 118,800 144,000 90,000 144,000
