5.3 Mounting
Unit may be set directly on a non-combustible floor or slab. (See CAUTION below.) Be
sure to comply with clearances in Paragraph 4.1.
WARNING
Whether suspended or mounted, unit must be supported
level for proper operation. Do not place or add additional
weight to a suspended unit. See Hazard Levels, page 2.
CAUTION: If installing a high efficiency Model SHH and/or the
system has an optional cooling coil module; there must be enough
height to install a condensate drain trap. See requirements in
Paragraph 6.6.3. NOTE: If a gravity condensate drain system is
not possible, a field-provided condensate pump may be installed.
Follow the pump manufacturer’s instructions.
TABLE 7B -
Suspension Point
Dimensions - SHH
Suspension
Points
(qty)
SHH 130, 180 SHH 260 SHH 350
Corner to
Corner Hanger
Point Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Corner to
Corner
Hanger Point
Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Corner to
Corner
Hanger Point
Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Configuration
Dimensions (inches)
Basic (blower/furnace) 4 82-5/16 N/A
32-5/8
N/A 82-5/16 N/A
48-7/8
N/A 82-5/16 N/A
56-7/8
N/A
with Mixing Box (MXB) 6 113-3/8 79-21/32
35-3/4
113-3/8 79-21/32
52
113-3/8 79-21/32
60
with Coil Cabinet (AU 5 or 6) 6 110-5/8 79-21/32 110-5/8 79-21/32 110-5/8 79-21/32
w/Coil Cabinet w/reheat (AU7) 6 135-3/16 79-21/32 135-3/16 79-21/32 135-3/16 79-21/32
with MXB & AU5 or AU6 8 141-3/16
79-21/32
141-3/16
79-21/32
141-3/16
79-21/32
107-1/2 107-1/2 107-1/2
with MXB & AU7 8 166-1/4
79-21/32
166-1/4
79-21/32
166-1/4
79-21/32
132-1/2 132-1/2 132-1/2
Dimensions (mm)
Basic (blower/furnace) 4 2091 N/A
829
N/A 2091 N/A
1241
N/A 2091 N/A
1445
N/A
with Mixing Box (MXB) 6 2886 2023
908
2886 2023
1321
2886 2023
1524
with Coil Cabinet (AU 5 or 6) 6 2810 2023 2810 2023 2810 2023
w/Coil Cabinet w/reheat (AU7) 6 3434 2023 3434 2023 3434 2023
with MXB & AU5 or AU6 8 3586
2023
3586
2023
3586
2023
2731 2731 2731
with MXB & AU7 8 4223
2023
4223
2023
4223
2023
3366 3366 3366
TABLE 7C -
Suspension Point
Dimensions - PXH
with hot water
heat module (HW)
Suspension Points
(qty)
PXH 000A with HW2 PXH 000B with HW2 PXH 000C with HW2 PXH 000D with HW2 PXH 000E with HW2
Corner to
Corner Hanger
Point Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Corner to
Corner Hanger
Point Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Corner to Corner
Hanger Point
Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Corner to Corner
Hanger Point
Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Corner to Corner
Hanger Point
Length
Discharge
Corner Hanger
Point To
Intermediate
Side Hanger
Points
Corner to
Corner
Hanger
Point
Width
Intermediate
Side Hanger
Point Width
Configuration
Dimensions (inches)
PXH with HW2, hot water
heat module
4 73-3/16 N/A
32-5/8
N/A 73-3/16 N/A
42-5/8
N/A 88-7/8 N/A
32-5/8
N/A 88-7/8 N/A
48-7/8
N/A 88-7/8 N/A
56-7/8
N/A
with Evap Cooler (ECC) 4 104-1/4 N/A N/A 104-1/4 N/A N/A 120-3/16 N/A N/A 120-3/16 N/A N/A 120-3/16 N/A N/A
with Mixing Box (MXB) 6 104-1/4 70-17/32 N/A 104-1/4 70-17/32
45-3/4
120-3/16 86-7/32
35-3/4
120-3/16 86-7/32
52
120-3/16 86-7/32
60
with Coil Cabinet
(AU 5 or 6)
6 101 70-17/32
35-3/4
101 70-17/32 116-11/16 86-7/32 116-11/16 86-7/32 116-11/16 86-7/32
with Coil Cab (AU7) 6 126-1/16 70-17/32 126-1/16 70-17/32 141-3/4 86-7/32 141-3/4 86-7/32 141-3/4 86-7/32
with ECC & MXB 6 132-5/16 70-17/32 132-5/16 70-17/32 151 86-7/32 151 86-7/32 151 86-7/32
with ECC & AU5 or AU6 6 132-1/16 70-17/32 132-1/16 70-17/32 147-3/4 86-7/32 147-3/4 86-7/32 147-3/4 86-7/32
with ECC & AU7 6 157-7/16 70-17/32 157-7/16 70-17/32 172-13/16 86-7/32 172-13/16 86-7/32 172-13/16 86-7/32
with MXB & AU5 or AU6 6 132-1/16 98-11/32 132-1/16 98-11/32 147-3/4 114-1/16 147-3/4 114-1/16 147-3/4 114-1/16
with MXB & AU7 6 157-7/16 123-11/32 157-7/16 123-11/32 172-13/16 139-1/16 172-13/16 139-1/16 172-13/16 139-1/16
with ECC, MXB, & AU5
or AU6
6 163-1/16 98-11/32 163-1/16 98-11/32 178-13/16 114-1/16 178-13/16 114-1/16 178-13/16 114-1/16
with ECC, MXB, & AU7 6 188-1/8 123-11/32 188-1/8 123-11/32 203-7/8 139-1/16 203-7/8 139-1/16 203-7/8 139-1/16
Dimensions (mm)
PXH with HW2, hot water
heat module
4 1859 N/A
829
N/A 1859 N/A
1083
N/A 2257 N/A
829
N/A 2257 N/A
1241
N/A 2257 N/A
1445
N/A
with Evap Cooler (ECC) 4 2648 N/A N/A 2648 N/A N/A 3053 N/A N/A 3053 N/A N/A 3053 N/A N/A
with Mixing Box (MXB) 6 2648 1791
908
2648 1791
1162
3053 2190
908
3053 2190
1321
3053 2190
1524
with Coil Cabinet
(AU 5 or 6)
6 2565 1791 2565 1791 2964 2190 2964 2190 2964 2190
with Coil Cab (AU7) 6 3202 1791 3202 1791 3600 2190 3600 2190 3600 2190
with ECC & MXB 6 3361 1791 3361 1791 3835 2190 3835 2190 3835 2190
with ECC & AU5 or AU6 6 3354 1791 3354 1791 3753 2190 3753 2190 3753 2190
with ECC & AU7 6 3999 1791 3999 1791 4389 2190 4389 2190 4389 2190
with MXB & AU5 or AU6 6 3354 2498 3354 2498 3753 2897 3753 2897 3753 2897
with MXB & AU7 6 3999 3133 3999 3133 4389 3532 4389 3532 4389 3532
with ECC, MXB, & AU5
or AU6
6 4142 2498 4142 2498 4542 2897 4542 2897 4542 2897
with ECC, MXB, & AU7 6 4778 3133 4778 3133 5178 3532 5178 3532 5178 3532
Option Key:
ECC = Evaporative Cooling Module
MXB = Mixing Box Module
AU5 = DX Cooling Coil Module
AU6 = Chilled Water Cooling Coil
Module
AU7 = DX Cooling Coil Module with
Reheat Pump
HW = Hot Water Heat Coil
