User’s Manual of NS3702-24P-4S

APPENDIX A: Networking Connection

A.1 PoE RJ-45 Port Pin Assignments

PIN NO

RJ-45 POWER ASSIGNMENT

1

 Power +

2

 Power +

3

 Power -


6

 Power -


A.2 Switch's Data RJ-45 Pin Assignments - 1000Mbps, 1000Base-T

PIN NO

MDI

MDI-X

1 BI_DA+ BI_DB+

2 BI_DA- BI_DB-

3 BI_DB+ BI_DA+

4 BI_DC+ BI_DD+

5 BI_DC- BI_DD-

6 BI_DB- BI_DA-

7 BI_DD+ BI_DC+

8 BI_DD- BI_DC-


Implicit implementation of the crossover function within a twisted-pair cable, or at a wiring panel, while not expressly forbidden,

is beyond the scope of this standard.
