242

Ethernet Type Parameters

The Ethernet Type parameters can be configured when Frame Type "Ethernet Type" is selected.

Object

Description

EtherType Filter

Specify the Ethernet type filter for this ACE.

Any

: No EtherType filter is specified (EtherType filter status is

"don't-care").

Specific

: If you want to filter a specific EtherType filter with this ACE,

you can enter a specific EtherType value. A field for entering a

EtherType value appears.

Ethernet Type Value

When "Specific" is selected for the EtherType filter, you can enter a specific

EtherType value.

The allowed range is 0x600 to 0xFFFF but excluding 0x800(IPv4), 0x806(ARP)

and 0x86DD(IPv6). A frame that hits this ACE matches this EtherType value.

Buttons

: Click to apply changes

: Click to undo any changes made locally and revert to previously saved values.

: Return to the previous Page.
