311

that are matched in static entries on the specific port.

Buttons

: Click to translate all dynamic entries to static entries.

: Click to apply changes

:

Click to undo any changes made locally and revert to previously saved values.

4.12.11 IP Source Guard Static Table

This Page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in

Figure 4-12-11

appears.

Figure 4-12-11:

Static IP Source Guard Table Screen Page Screenshot

The Page includes the following fields:

Object

Description

Delete

Check to delete the entry. It will be deleted during the next save.

Port

The logical port for the settings.

VLAN ID

The VLAN ID for the settings.

IP Address

Allowed Source IP address.

MAC Address

Allowed Source MAC address.

Buttons

: Click to add a new entry to the Static IP Source Guard table.

: Click to apply changes

:

Click to undo any changes made locally and revert to previously saved values.
