30

1. It is recommended to use IFS SFPs on the Managed Switch. If you insert an SFP transceiver that is

not supported, the Managed Switch will not recognize it.

2. Port 21 to Port 24 are a shared SFP slot that supports the Gigabit and Fast Ethernet SFP

transceiver.

1.

Before we connect the NS3702 to the other network device, we have to make sure both sides of the SFP transceivers are with

the same media type, for example: 1000Base-SX to 1000Base-SX, 1000Bas-LX to 1000Base-LX.

2.

Check whether the fiber-optic cable type matches with the SFP transceiver requirement.

To connect to 1000Base-SX SFP transceiver, please use the multi-mode fiber cable with one side being the male duplex

LC connector type.

To connect to 1000Base-LX SFP transceiver, please use the single-mode fiber cable with one side being the male duplex

LC connector type.

Connect the Fiber Cable

1.

Insert the duplex LC connector into the SFP/SFP+ transceiver.

2.

Connect the other end of the cable to a device with SFP/SFP+ transceiver installed.

3.

Check the LNK/ACT LED of the SFP/SFP+ slot on the front of the Managed Switch. Ensure that the SFP/SFP+ transceiver is

operating correctly.

4.

Check the Link mode of the SFP/SFP+ port if the link fails. To function with some fiber-NICs or Media Converters, user has to

set the port Link mode to “1000 Force” or “100 Force”.

Remove the Transceiver Module

1.

Make sure there is no network activity anymore.

2.

Remove the Fiber-Optic Cable gently.

3.

Lift up the lever of the SFP module and turn it to a horizontal position.

4.

Pull out the module gently through the lever.
