282
counted as a retransmit as well
as a timeout. A send to a
different server is counted as a
Request as well as a timeout.
This section contains information about the state of the server and the latest round-trip time.
Name RFC4668 Name Description
IP Address - IP address and UDP port for the authentication server
in question.
State - Shows the state of the server. It takes one of the
following values:

Disabled : The selected server is disabled.

Not Ready : The server is enabled, but IP
communication is not yet up and running.

Ready : The server is enabled, IP communication
is up and running, and the RADIUS module is
ready to accept access attempts.

Dead (X seconds left) : Access attempts were
made to this server, but it did not reply within the
configured timeout. The server has temporarily
been disabled, but will get re-enabled when the
dead-time expires. The number of seconds left
before this occurs is displayed in parentheses.
This state is only reachable when more than one
server is enabled.
 Other Info
Round-Trip
Time
radiusAuthClient
ExtRoundTripTim
e
The time interval (measured in milliseconds) between
the most recent Access-Reply/Access-Challenge and
the Access-Request that matched it from the RADIUS
authentication server. The granularity of this
measurement is 100 ms. A value of 0 ms indicates
that there hasn't been round-trip communication with
the server yet.
RADIUS Accounting Statistics
The statistics map closely to those specified in RFC4670 - RADIUS Accounting Client MIB. Use the server select box to switch
