101

The Page includes the following fields:

.Object

Description

Group ID

Indicates the group ID for the settings contained in the same row. Group ID

"Normal" indicates there is no aggregation. Only one group ID is valid per port.

Port Members

Each switch port is listed for each group ID. Select a radio button to include a port

in an aggregation, or clear the radio button to remove the port from the

aggregation. By default, no ports belong to any aggregation group.

Buttons

: Click to apply changes

: Click to undo any changes made locally and revert to previously saved values.

4.5.2 LACP Configuration

Link Aggregation Control Protocol (LACP) - LACP LAG negotiate Aggregated Port links with other LACP ports located on a different

device. LACP allows switches connected to each other to discover automatically whether any ports are member of the same LAG.

This Page allows the user to inspect the current LACP port configurations, and possibly change them as well. The LACP port

settings relate to the currently selected stack unit, as reflected by the Page header. The LACP Configuration screen in

Figure 4-5-4

appears.
